Description
Kingspan Alumilite Model Skylight, Curb Mount with Pre-Attached Curb Seal Tape, Double Glazed, White Polycarbonate over Opal 16MM Triple Wall Polycarbonate Panel, Thermally Broken Aluminum Frame, Mill Finish, U-Factor .49, Skylight Frame Inside Dimension 50.5" x 93.5"
Research behind this product: the U.S. Department of Energy's study of commercial building toplighting, in our daylighting library.
Full Specifications
- Warranty
-
Documents
Kingspan Alumilite Model Skylight, Curb Mount with Pre-Attached Curb Seal Tape, Double Glazed, White Polycarbonate over Opal 16MM Triple Wall Polycarbonate Panel, Thermally Broken Aluminum Frame, Mill Finish, U-Factor .49, Skylight Frame Inside Dimension 50.5" x 93.5"
Research behind this product: the U.S. Department of Energy's study of commercial building toplighting, in our daylighting library.
Full Specifications
Inside Frame Dimension50.5x93.5
Nominal Size4' x 8'
Fabricated to fit Curb Outside Dimension49x92
Estimated Number Per Pallet20
Estimated Number of Pallets Per 48' Flatbed10
Glazing TypeWhite Polycarbonate over Opal Polycarbonate
Glazing LayersDouble Glazed
