Description
Velux Dynamic Dome Skylight, LuxGuard Double Dome Model, Curb Mount, Double glazed, Clear Smooth UV Guard Polycarbonate over White Prismatic Polycarbonate, Thermally Broken Aluminum Frame, Mill Finish, FM Approved, Skylight Frame Inside Dimension 40.5" x 124.5"
Research behind this product: the U.S. Department of Energy's study of commercial building toplighting, in our daylighting library.
Full Specifications
- Warranty
- Videos
-
Documents
Velux Dynamic Dome Skylight, LuxGuard Double Dome Model, Curb Mount, Double glazed, Clear Smooth UV Guard Polycarbonate over White Prismatic Polycarbonate, Thermally Broken Aluminum Frame, Mill Finish, FM Approved, Skylight Frame Inside Dimension 40.5" x 124.5"
Research behind this product: the U.S. Department of Energy's study of commercial building toplighting, in our daylighting library.
Full Specifications
Inside Frame Dimension40.5x124.5
Nominal Size3' x 10'
Fabricated to fit Curb Outside Dimension39x123
Estimated Number Per Pallet25
Estimated Number of Pallets Per 48' Flatbed8
Hail Rating2"
Glazing TypeClear Smooth Polycarbonate over White Prismatic Polycarbonate
Glazing LayersDouble Glazed
U-Factor.65
Solar Heat Gain Coefficient (SHGC).46
Visible Light Transmittance (VLT).62
