Description
The Taylon 4896 ULVSV combines a UL-listed automatic smoke vent with a MAXAIR vented base, so one opening in the roof provides daylight, everyday passive ventilation and fire venting. The upper unit is the same UL 793 listed Diamond Series smoke vent as the 4896 ULSV, with a fusible link release and G90 galvanized mechanism; the base beneath it is G90 galvanized steel with 11 square feet of ventilation area, an integrated rain shield, bird screen, insect screen and dust filter. Logistics Lighting confirms the curb fit, quotes the unit and ships direct from Taylon.
Key features of the 4896 ULVSV
- Three functions in one opening. Daylighting, passive ventilation and UL 793 smoke venting.
- MAXAIR base. 11 sq ft of free area with a rain shield that stops wind-driven rain; screens and dust filter standard.
- UL listed. UL file E533253, UL 793, NFPA 204, California and international fire codes.
- Automatic and manual release. Fusible link options of 165, 212, 286, 370 or 520 F; inside, outside or both release handles.
- Rated. 1,000 lb impact, 130 mph wind, 10 psf (30 psf available), roof Class 90.
- Made in the USA.
Specifications
- Nominal size 4 x 8; inside curb dimension 48 x 96 in; fits a 51 x 99 in outside curb
- Glazing: single white Diamond Series polycarbonate dome, 80% VLT, 0.58 SHGC, 100% diffusion; dual glazing and metal lids available
- Smoke vent mechanism: G90 galvanized curb frame, dome frame, hinge, shock brackets, lifting shocks, latch and striker; EPDM bulb gasket
- Vented base: G90 galvanized steel MAXAIR, 11 sq ft ventilation, rain shield, bird and insect screens, dust filter
- Fusible link: 165, 212, 286, 370 or 520 F, UL/FM
- Weight: about 217 lb
- Other sizes: 4848, 4872, 6072 and 6467
Where the ULVSV fits
Specify the ULVSV on unconditioned warehouses and industrial buildings where the code requires smoke vents and the owner wants passive airflow without fans. For fire venting alone, the 4896 ULSV is lighter and lower in cost; for daylight and ventilation without a listing, the 4896 ISPV. Sunoptics' SVT2CV 4080 is the comparable continuous-vent smoke vent. Curbs are on the roof curbs page; because the vent is operable it takes interior safety screens only.
Frequently asked questions
How much airflow does the base provide? Taylon rates the MAXAIR base at 11 square feet of ventilation area per unit.
Does the vented base affect the UL listing? No. The smoke vent above it is the listed assembly; the base is a ventilation curb extension.
How tall is the whole unit? The base adds height above the curb; the cut sheet in the Documents tab shows the section, and we check clearances on the quote.
How to get a quote
Send the smoke vent worksheet or call 307-633-9696 with quantity, curb outside dimension, link temperature, release option and ship-to address. We confirm the current Taylon lead time on the quote. The cut sheet, vented base data sheet and three-part specification are in the Documents tab.
Related reading: OSHA fall protection for skylights and roof openings, in our daylighting library.
