Description
The Bilco LU-1 is the Ladder Up safety post: a telescoping steel post that mounts permanently to the top two rungs of a fixed ladder and extends above the roof hatch, floor door or manhole so the climber can step on and off the ladder upright and balanced, with a positive handhold. It is the standard companion to a Bilco roof hatch and Bil-Guard rail. Logistics Lighting quotes the LU-1 with the hatch and rail and ships direct from Bilco.
Key features of the Ladder Up LU-1
- Locks automatically when fully extended; a release lever disengages it to return to the lowered position.
- Controlled movement up and down from a stainless steel balancing spring, so the post does not slam.
- Fits most ladders. Adjustable mounting brackets suit rung spacing up to 14 inches on center and clamp brackets take rungs up to 1-3/4 inches in diameter.
- Pre-assembled from the factory with a pull-up loop at the top for raising the post.
- Corrosion resistant. Yellow powder coat over steel, Type 316 stainless mounting hardware, five-year warranty.
Specifications
- Model LU-1: steel, safety yellow powder coat
- Post: high-strength square tubing, telescoping, pull-up loop at upper end
- Balancing spring: stainless steel
- Mounting: adjustable brackets for rung spacing up to 14 in (356 mm); clamp brackets for rungs up to 1-3/4 in (44 mm)
- Hardware: Type 316 stainless steel, included
- Related models: LU-2 hot-dip galvanized steel, LU-3 Type 304 stainless steel with special alloy spring for corrosive atmospheres, LU-4 mill aluminum, all quoted on request
Why the post matters
OSHA 1910.23 requires a fixed ladder's side rails to extend 42 inches above the landing, or a grab bar that does the same job. Most hatch ladders stop below the curb, which leaves the climber pulling themselves through the opening with nothing to hold. The LU-1 restores the handhold without changing the ladder. Pair it with a hatch rail such as the RL2-S on the S-20 or the RL2-STB on the S-50TB. Babcock Davis offers a comparable post, the BSPY.
Frequently asked questions
Will the LU-1 fit a ladder that is not a Bilco product? Yes. It clamps to any fixed ladder with rung spacing up to 14 inches and rungs up to 1-3/4 inches in diameter.
Does it work on floor access doors? Yes. Bilco lists it for roof hatches, floor access doors and manholes.
Is it hard to install? No. It bolts to the top two rungs with the supplied hardware; the installation manual is in the Documents tab.
How to get a quote
Send the ladder and hatch worksheet or call 307-633-9696 with the ladder rung size and spacing if you know them, and the hatch it serves. We confirm the current Bilco lead time on the quote. The cut sheet, installation manual and three-part specification are in the Documents tab.
Related reading: OSHA fall protection for skylights, in our daylighting library.
